Wheel Light Sizes Explained
Wheel Light Fitment:
Choose between 15.5", 17", and 20" Wheel Lights to fit your vehicle perfectly!
We offer Wheel Lights in different sizes to fit around the different sized braking assemblies of vehicles. Every vehicle is slightly different and different sizes so this way you can get the perfect sized Wheel Light for your vehicle.
Most Full size trucks require the 17" Wheel Lights(Such as most Diesels and 2008+ F150s). The 15.5" Wheel Lights are for smaller trucks like Tacomas, Colorados, Rangers, and most cars. 20" Rings are specifically designed and made for Duallys(DRW F350s can use the 17" Wheel Lights. F450s need the 20" Ring).
20" Wheel Lights are made specifically for F450s and 3500s Duallys - To be able to clear 20" Wheel Lights you need AT LEAST a 24" Wheel with 26" Wheels being suggested.
17" - To be able to clear 17" Wheel Lights you need AT LEAST a 20" Wheel(with no valve stem in the back side of the wheel) - with 22" Wheel being suggested.
15.5" - To be able to clear 15.5" Wheel Lights you need AT LEAST a 18" Wheel
If you run a 18" wheel with a 17" Wheel Light, or a 16" Wheel with a 15.5" Wheel Light the Wheel will literally grind the Wheel Light down and destroy the Wheel Light also likely causing a short and ripping the wire off. The Wheel Light size is the ID of the Ring, NOT the OD. You want a gap between the Wheel and Wheel Light so the Wheel Light can both not be damaged by the Wheel and have distance to shine and light up the area.
OR
If your wheels stick out further than your dust shield then the above information does not matter and you just need a wheel light that can clear your braking assembly. We've collected the fitment information below over time that we found works best for us. Please note that they might be a tight fit and this is what we have found works best. Still measure your system and find what works best for you as it may be slightly different than us.
WE ARE NOT RESPONSIBLE IF YOU CHOOSE THE INCORRECT SIZE.
FORD
F150 - 96-08 - 15 Inch Ring
F150 - 08-Current - 17 Inch Ring
F250/350 - ALL YEARS - 17 Inch Ring
F450 - ALL YEARS - 20 Inch Ring
GM/CHEVY
1500 - ALL YEARS - 15 Inch Ring
2500 - ALL YEARS - 17 Inch Ring
3500 - ALL YEARS - 20 Inch Ring
DODGE
1500 - Older than 2008 - 15 Inch Ring
1500 - 08 - Current 17 Inch Ring
2500+ ALL YEARS - 17 Inch Ring
3500 ALL YEARS - 20 Inch Ring
TOYOTA
Tacoma - 15 Inch Ring
Tundra - 17 Inch Ring
